Genesis Caribou Fat Bike 2016

Product Code: 145565
We're sorry, this product is no longer available.
Product Description

Originally conceived for use on Alaskan snow, the key to a ‘fatbike’ is its large volume/ low pressure tyre combo (generally 3.8”+) which provides enough floatation and traction to pedal over soft, unstable and otherwise un-passable terrain. Aka, perfect for exploring the path less travelled!

Not tied-down to specific single-season use, and much, much more than a just ‘snow bike’, the trail-orientated geometry and fat tyres lend themselves well to year-round use, excelling equally as well in typical UK riding conditions like mud, bog, wet roots and loose rock as with the white stuff.

Roll over (and up) just about anything, find grip and traction in places where previously you’d find none, feel the natural ‘cush’ and obscene amounts of deflection smooth out the trail ahead (try 6-12psi for starters), load it up and head out for an adventure where no other bike dare tread. About as much fun as you can have on a two wheels without an engine!


Mjölnir chromoly

AKA ‘Thor’s Hammer’ and pronounced ‘Myol-n(ee)r‘. Our new double-butted, cold-drawn, seamless, Taiwanese chromoly tubeset also goes by the aliases of 4130, Cr-Mo and Chromo. It’s a like-for-like replacement for other, identical branded chromoly tubing and ultimately means a saving can be passed onto you via either a healthy price drop or a little more room for up-speccing without sacrificing performance.

Alt handlebar

With an unconventional 20° backsweep, our new Alt bars might (ok, do) look a little weird and take a few rides to get used to but once you do you’ll appreciate the better handling and supreme comfort, especially over long distances they offer by allowing the wrists and shoulders to be positioned at a more neutral/natural angle (put your arms in front of you and notice the position to which the wrists naturally fall). With enough forward wiggle to not need any stem compensation and a trail-friendly 720mm width or trim-able if you so wish.

TRP Spyke

New TRP Spyke mechanical disc brakes (think mtb version of their Spyre) replace last years’ Shimano hydraulics for easier middle-of-nowhere serviceability and repairs. Same dual-piston action as the Spyre (no static slave piston = better pad/rotor clearance, no rubbing and easier setup) and combo'd with Jagwire KEB-SL compressionless cable outer for optimum performance.

Fatbike-friendly 1x10

The new, lower geared 30T RaceFace Ride XC chainset replaces last years’ 32T version for a better Fatbike-friendly spread of gears (paired to wide-range 11-36T cassette).

Read more
* Prices are estimates and will be calculated at checkout based on your minimum deposit.
Questions and Answers

There are currently no questions and answers for this product.

Want to ask us a question about this product? Just fill in the form below and we will get back to you as soon as we can.

Customer Reviews

There are currently no reviews for this product.

  • 0/5 Stars

(Be the first to review)
Recently bought this item? Leaving a review can be helpful to us and to other customers. If you would like to leave a review please fill in the form below.
  • 4/5 Stars

Sorry there is no size guide entered for this product yet. If you would like to know more please contact us or ask us a question and we will be happy to help.


Frame and Fork

Frame: Genesis Mjölnir Seamless Double-Butted Cromoly

Fork: Alu 100mm Sus-corrected w/ 1-1/8" Steerer &

Headset: FSA NO.21/12B/44 (?44-34mm)

Colour: Flash Green

Weight: 16.56kg (Med w/o pedals)

Sizes: S/M/L/XL


Shifters: Shimano Deore SL-M610

Rear Derailleur: Shimano Deore RD-M615

Front Derailleur: Shimano Deore FD-M617-D w/ Adaptor

Chainset: Samox TAF29-231AA, 36/22T

Bottom Bracket: Samox BB-EB2401, 100mm

Chain: KMC X10

Freewheel: Shimano CS-HG50, 11-36T

Wheels and Braking

Hubs: KT Sealed Cartridge 6-Bolt (150x15mm/170x9mm)

Rims: FATlab 80mm Tubeless-Ready, 32H

Spokes: 14G Stainless Silver DB w/ Brass Nipples

Tyres: CST BFT 26x4.0", 60TPI

Brakes: Shimano BR-M395 w/ SM-RT56 180/160mm Rotors

Brake Levers: Shimano BL-M425

Contact Zones

Handlebars: Genesis Flattop, 740mm x 9

Stem: Genesis Trail, 55mm x 0

Grips: Genesis Silicon, 130mm

Saddle: Genesis MTB

Seatpost: Genesis MTB,

Seat Clamp

Pedals:P VP-535


Caribou Geometry

1 - Horizontal Toptube Length (mm)602619659685
2 - Seat Angle (°)73737373
3 - Headtube Length (mm)100100110115
4 - Head Angle (°)70707070
5 - Seat Tube Length (C-T, mm)380432480535
6 - BB Drop (mm)55555555
7 - Chanstay Length (mm)452452452452
8 - Fork Offset (mm)51515151
9 - Trail (mm)94949494
10 - Wheelbase Length (mm)1121115011791205
12 - Stack (mm)633638638652
13 - Reach (mm)411440465490
Stem (mm)55555555
Handlebar (mm)760760760760
Crankarm (mm)170175175175
