GIANT REVOLT X ADVANCED PRO 0 GRAVEL BIKE 2024 - GLOSS KELP FOREST/CHARCOAL/CHROME
Skip to product information
1 of 7

Product Details

Washboard descents, sketchy dirt, gravel and rocks of all shapes and sizes. You never know what you’ll get on a gravel ride. This composite gravel machine has front suspension and engineered compliance to help you float through it all with speed and control.

Composite frameset is designed specifically for front suspension. With 40mm of travel, the fork absorbs impacts so you can ride smoother and faster on rugged gravel and dirt.

Lowered seatstays with smaller diameter tubes absorb road shocks and vibrations. A Contact SL XR D-Fuse handlebar adds more compliance without sacrificing the stiffness needed for cornering, sprinting or climbing.

A flip chip on the rear dropout adjusts the wheelbase short for quicker handling, or long for improved stability at speed. The long setting also allows for larger diameter tyres up to 53mm.

Features

  • Advanced-grade Carbon Fibre Frame: Super lightweight & durable.
  • SRAM Force eTap AXS 12 Speed: Quality wireless shifting with a wide range for all terrain.
  • Giant Carbon Wheelset: With tubeless technology for increased grip & reduced risk of punctures.
Full Specification:
  • Frame: Advanced-grade composite, 12x142mm thru-axle, disc, flip chip dropout
  • Fork: Fox 32 Float AX Performance Elite, 40mm, Fit 4 damper12x100mm thru-axle
  • Gear Shifters: SRAM Force eTap AXS, 1x12
  • Chainset: SRAM Rival D1 DUB, 40t XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
  • Rear Cassette: SRAM XG-1295, 12-speed, 10x52
  • Chain: SRAM X01 Eagle
  • Front Derailleur: N/A
  • Rear Derailleur: SRAM X01 Eagle AXS
  • Bottom Bracket: SRAM DUB, press fit
  • Pedals: Not supplied
  • Rims: Giant CXR 1 X1 Carbon Disc WheelSystem, [F] 25.8mm, [R] 25.8mm
  • Front Hub: Giant CXR X alloy, CenterLock, 12mm thru-axle
  • Rear Hub: Giant CXR X alloy, 60t ratchet driver, CenterLock, 12mm thru-axle
  • Tyres: Maxxis Rambler, 700x50c, tubeless
  • Brakes: SRAM Force eTap AXS hydraulic, SRAM CenterLine rotors [F]160mm, [R]160mm
  • Handlebars: Giant Contact SL XR D-Fuse, 31.8mm XS:44cm, S:44cm, M:46cm, M/L:46cm, L:48cm, XL:48cm
  • Handlebar Tape: Stratus Lite 3.0
  • Stem: Giant Contact, 8-degree XS:50mm, S:50mm, M:60mm, M/L:70mm, L:70mm, XL:80mm
  • Saddle: Giant Approach SL
  • Seatpost: Post Moderne, dropper, 30.9mm with 30mm of suspension XS:365mm / 75mm drop S:415mm / 100mm drop
  • Accessories: Tubeless prepared, 53mm max tyre size in "long" flip chip position, 45mm max tyre size in "short" flip chip position
  • Weight: Not Available

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based on pre-production painted frames at time of publication. Weights may vary in final production.




How to Build Your Bike

Aftercare





GIANT REVOLT X ADVANCED PRO 0 GRAVEL BIKE 2024 - GLOSS KELP FOREST/CHARCOAL/CHROME

Regular price £5,524.00
Save 15%
Regular price Was £6,499.00 Sale price £5,524.00
