SHIMANO TIAGRA BR-4770 FLAT-MOUNT FRONT BRAKE CALIPER

SHIMANO TIAGRA BR-4770 FLAT-MOUNT FRONT BRAKE CALIPER

Skip to product information
1 of 1

Product Details

Hydraulic road disc brake caliper Shimano Tiagra BR-4770 for front with Flat-Mount and disc pads.

Specifications

Overview
  • High performance low profile Tiagra hydraulic road disc brake for efficient braking in all conditions
  • Front wheel use for flat mount forks with adapter to flip between 140 and 160 mm
  • Oversized 22mm ceramic pistons optimized for heat insulation, lightweight and stiffness
  • Opposed 2-piston design reduces leading effect and optimal pad wear increases braking control
  • Increased pad to rotor clearance reduces the chance of rotor drag
  • Forged calliper design is lightweight and rigid
  • One way internal fluid circuit makes bleeding easy
  • Mineral oil brake fluid is non-corrosive and less hazardous than conventional hydraulic brake fluid
  • Shim-less mounting bracket allows for quick installation and setting up
  • Recommended for use with SM-RT64 rotors for optimum braking performance
  • Comes complete with K03S resin compound pads
  • Inline hose routing for low profile design
Specification
  • Use: Road/Cyclocross
  • Group: Tiagra
  • Model: BR-4770
  • Brake type: Disc-Brake
  • Mount: front
  • Brake mounting: Flat-Mount
  • Brake pads: Resin
  • One-Way bleeding: Yes
  • Brake fluid: Mineral oil
  • Recommended brake lever: ST-4720, ST-4725
  • Recommended brake hose: SM-BH90-JK-SSR/SM-BH90-J-SSR
  • Recommended brake rotor: SM-RT70 (140mm/160mm)
Material
  • Aluminum, painted
Colour
  • Grey
Weight
  • Approx. 150g with adapter (manufacturer information)

Brake hose and Mineral oil not included!

SHIMANO TIAGRA BR-4770 FLAT-MOUNT FRONT BRAKE CALIPER

SHIMANO TIAGRA BR-4770 FLAT-MOUNT FRONT BRAKE CALIPER

Regular price £49.49
Save 10%
Regular price Was £54.99 Sale price £49.49

SKU: BR4770F

Product ID: 156519

EPOS Code:


View full details

Product Description

Hydraulic road disc brake caliper Shimano Tiagra BR-4770 for front with Flat-Mount and disc pads.

Specifications

Overview
  • High performance low profile Tiagra hydraulic road disc brake for efficient braking in all conditions
  • Front wheel use for flat mount forks with adapter to flip between 140 and 160 mm
  • Oversized 22mm ceramic pistons optimized for heat insulation, lightweight and stiffness
  • Opposed 2-piston design reduces leading effect and optimal pad wear increases braking control
  • Increased pad to rotor clearance reduces the chance of rotor drag
  • Forged calliper design is lightweight and rigid
  • One way internal fluid circuit makes bleeding easy
  • Mineral oil brake fluid is non-corrosive and less hazardous than conventional hydraulic brake fluid
  • Shim-less mounting bracket allows for quick installation and setting up
  • Recommended for use with SM-RT64 rotors for optimum braking performance
  • Comes complete with K03S resin compound pads
  • Inline hose routing for low profile design
Specification
  • Use: Road/Cyclocross
  • Group: Tiagra
  • Model: BR-4770
  • Brake type: Disc-Brake
  • Mount: front
  • Brake mounting: Flat-Mount
  • Brake pads: Resin
  • One-Way bleeding: Yes
  • Brake fluid: Mineral oil
  • Recommended brake lever: ST-4720, ST-4725
  • Recommended brake hose: SM-BH90-JK-SSR/SM-BH90-J-SSR
  • Recommended brake rotor: SM-RT70 (140mm/160mm)
Material
  • Aluminum, painted
Colour
  • Grey
Weight
  • Approx. 150g with adapter (manufacturer information)

Brake hose and Mineral oil not included!
