SRAM DB6 STEALTH DISC BRAKE

Pairing heavy-duty power with a modern integrated cockpit, DB6 brakes lets you focus on the ride.

The low maintenance Mineral Oil system uses all new lever architecture which features easy adjustment access and ergonomic comfort.

The right and left specific stealth lever body design brings the hose parallel to the bar, allowing for an organized cockpit that pairs perfectly with mechanical Eagle Transmission shifters. Consistent heavy-duty power is no surprise, as DB6 shares the same proven calliper architecture as DB8.

Features

• Stealth lever architecture pairs perfectly with mechanical Eagle Transmission shifters
• Split ring clamp compatible with SRAM MMX-compatible shifters and Dropper Lever
• Code-like heavy duty power
• Left and right specific levers feature tooled lever reach adjust
• Uses existing SRAM Large brake pads
• Designed for use with Maxima Mineral Oil only
• Designed for use with SRAM Mineral Oil Bleed Kit only

Specification

• Application: MTB
• Brake type: Hydraulic
• Calliper construction: 2-piece
• Pistons: 4
• Pad type: Steel-backed Organic
• Bracket: Direct Mount DIR
• Hydraulic fluid: SRAM Mineral Oil
• Lever pivot: Bushing
• Contact adjust: Yes
• Reach adjust: Tooled
• Calliper bleed port: Threaded
• Rotor type recommended: 1-piece Centreline (not included!)

Mounting / Hose Length

• Front - 2000 mm
• Rear - 2000 mm

Material

• Lever: Aluminium
• Body: Aluminium
• Calliper: Aluminium
• Pistons: Phenolic Plastic
• Bolts: Steel

Colour

• Diffusion Black Anodized

Weight

• 365 g

Contents

• 1 x DB6 Stealth Disc Brake
• 1 x MatchMaker Clamp
• 2 x Fastening screws
• 1 x Insert pin
• 1 x Olive
• 1 x Transport safety
• Disc brake is ready for installation, completely assembled and bled!

Rotor and Adapter not included!
