Modern mountain bikes have redefined what riders are capable of, pushing the requirements for heavy-duty power further than ever before.
Maven Ultimate is the answer to that evolution, with monstrous 18 and 19.5-millimeter pistons driving 50% more power than Code. But best-in-class power means nothing unless you’re able to harness it.
Swinglink translates rider input for progressive power throughout the lever pull, maintaining SRAM’s signature ride feel. And because of a stiff 4-bolt caliper that sheds an incredible amount of heat, that feel remains consistent, so the last corner feels like the first corner. But with so much baseline power on hand, there is more range than ever before to tune the ride qualities to exactly how you want with different pad materials, and rotor sizes. Maven Ultimate pairs a sleek high polish lever body to a caliper with machined edges and titanium hardware for a finish worthy of any modern super bike. And for unrivaled ease of customization, features tool-free Reach and Contact Point Adjust. Maven is the expert, but Maven Ultimate is the pinnacle.
Features
- 18 and 19.5-millimeter pistons for best-in-class power
- SwingLink for signature SRAM lever feel
- Stiff 4-piston caliper with best heat management and easier bolt access
- Organic pads come standard for the best modulation and the quietest ride
- Stealth lever architecture for a sleeker, more modern ride
- Mineral oil for low maintenance and performance
- Designed for use with Maxima Mineral Brake Oil only
- Ultimate worthy polished lever body and titanium hardware
- Contact Point Adjust and tool-free Reach Adjust
Specification
-
Application: MTB
-
Brake type: Hydraulic
-
Calliper construction: 2-piece
-
Pistons: 4
-
Pad type: Steel-backed organic
-
Bracket: Direct Mount DIR
-
Hydraulic fluid: SRAM Mineral Oil
-
Lever pivot: Bearing
-
Contact adjust: No
-
Reach adjust: Tool-free
-
Calliper bleed port: Bleeding Edge
-
Rotor type recommended: 1-piece HS2 (not included!)
Mount
- Front - 950 mm
- Rear - 2000 mm
Material
-
Brake lever: Forged aluminum
-
Lever body: Forged aluminum
-
Brake caliper: Forged aluminum
-
Piston: Phenolic plastic
-
Bolts: Titanium
Colour
Weight
Contents
- 1 x Maven Ultimate Stealth Disc Brake
- 1 x Organic XL brake pads on steel backing plate
- 1 x MMX Clamp
- 1 x Olive
- 1 x Sleeve
- 1 x 20P-2 Adapter
- 2 x Caliper mounting bolt
- Disc brake is ready for installation, completely assembled and bled!
Rotor not included!
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Weights are based off pre-production products at time of publication. Weights may vary in final production.
