Zipp’s ultimate aero weapon is faster than ever, thanks to our proprietary Total System Efficiency technology.
With TSE, the 858 NSW Carbon Tubeless Disc-brake wheelset features a tubeless and hookless rim profile for seamless tire interface and huge drop in weight. The 858 gives you the benefits of our deep rims at weight typically associated with rims that are 20mm shallower. The wheel’s internal width is 23mm, ideal for running wider tires with lower pressures for decreased rolling resistance. That’s how TSE technology helps you conquer the four barriers to speed: Wind Resistance, Gravity, Rolling Resistance, and Vibration Losses.
The 858 NSW’s undulating 82mm-85mm deep rim shape, our patented Sawtooth profile, is our highest performing design for aero efficiency and crosswind stability. The result is the pure speed, especially for triathletes, time trial specialist, and any other speed freak. What’s more, while this wheelset is optimized for tubeless tires, you still have the option to run tubeless ready tires with tubes.
The 858 NSW is fastest with a 28mm tire. In triathlon, running wider tubeless tires at lower pressure makes you faster while also smoothing out the ride so your body is fresher for the run. Disc brakes also offer more reliable speed modulation and braking power in all weather conditions. The 858 NSW features the premium ZR1 SL hubset with ceramic bearings and 66 points of engagement.
Features
- Zipp’s most advanced and fastest deep-rim wheel for road, triathlon, and time trialling
- Weighs 30 g lighter than previous model
- Optimized for 30mm tires
- Minimum 28mm tire width
- TSE for greater efficiency and reduced rolling resistance
- Sawtooth rim with Hyperfoil nodes and HexFin ABLC dimple pattern for top aero and crosswind-stability performance with an undulating rim depth
- ZR1 SL hubset with ceramic bearings
- Zipp graphics applied using Zipp’s ImPress direct-print technology
Specification
-
Range of application: Road bike / Triathlon
-
Model: 858 NSW
-
Rim diameter: 28"
-
ETRTO: 622 mm
-
Rim profile: Symmetrical
-
Tyre interface: Hookless TSS
-
Rim type: Clincher (folding/wire tires)
-
Tubeless Ready: Yes
-
Hub type: ZR1 SL
-
Rim height: 82/85 mm
-
Outer width: 27 mm
-
Rim width: 23 mm
-
Axle system: 12 mm Thru Axle
-
Built-in dimension: 100 mm
-
Number of holes: 20
-
Spoke pattern: Two-cross (1:1)
-
Valve hole: Presta / SV Ø 6.5 mm
-
Brake interface: Disc Center Lock
-
Spokes: CX-Ray
-
Spoke length drive side: 230 mm
-
Spoke length non-drive side: 232 mm
-
Nipples: Sapim Secure-Loc
-
Maximum tire pressure: 5.0 Bar (73 psi)
-
Recommended system weight: 114 kg (body weight + bike + equipment)
Material
-
Rim: Carbon
-
Hub shell: Aluminium
-
Spokes: Aluminium
-
Nipples: Aluminium
Contents
- 1 x Zipp 858 NSW Carbon front wheel
- incl. 12 mm end cap
Thru axle not included!
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Weights are based off pre-production products at time of publication. Weights may vary in final production.
