Rudy XL is here to take you to the edge of dropbar domain.
With up to 60mm of tuneable travel and more tire clearance, it’s designed to add comfort and control to your gravel ride so you can unlock new terrain.
With Charger Race Day 2's rock-solid lockout in Rudy XL Ultimate, you can tackle rough paths comfortably without sacrificing tarmac efficiency.
Features
- Solo Air spring tuned for short travel
- Charger Race Day 2 Damper
- 50 mm or 60 mm travel options
- Fits up to 29x2.2 tires
- 2-bolt mounts to fit a short fender (RockShox fender sold separately)
Specification
-
Range of use: Gravel
-
Wheel size: 28"
-
Model designator: Ultimate
-
Spring: Solo Air
-
Damper type: Charger Race Day 2
-
Damping adjustments: Extl rebnd, 2 pos comp (open/lock)
-
Steerer: Tapered 1.5" to 1 1/8" (tapered)
-
Upper tube: 30 mm
-
Brake type: Flat mount (direct flat mount 160 mm)
-
Maximum rotor size: 180 mm
-
Dropouts: 12x100 mm Maxle Stealth thru axle
-
Max. Tire diameter: 716 mm
-
Max. Tire width: 55.5 mm
-
Crown OD: 60 mm
-
Offset: 45 mm
-
Maximum recommended system weight: 135 kg
-
E-bike approved: Yes
-
ASTMF2043-EN17406 Class: 2
-
Fender compatibility: Bolt On - Short
Travel / Axle to crown
- 50 mm / 460 mm
- 60 mm / 470 mm
Material
-
Steerer: Aluminum
-
Crown: Forged 7050 aluminum
-
Upper tube: Tapered Wall Aluminum, Fast Black
-
Lower leg: Magnesium
Colour
Contents
- 1 x RockShox Rudy XL Ultimate Race Day 2 Solo Air Tapered
- 1 x Rock Shox 12x100 mm Maxle Stealth thru axle
- 1 x Star nut
- 1 x Fender
We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, materials and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.
Weights are based off pre-production products at time of publication. Weights may vary in final production.
